Industrial LCD Panel 9.7 Inch for 4:3 Control Panels LVDS

9.7 Inch 1024×768 LVDS Industrial LCD Panel for 4:3 Control Panels

This 9.7 inch industrial LCD panel is prepared for 4:3 control panels, access-control equipment, service consoles and machine interfaces that still require XGA-style 1024×768 resolution. The public specification confirms 9.7 inch size, 1024×768 resolution, LVDS interface, 400 nits brightness, 6 o’clock viewing direction, no touch panel in the standard configuration, -20 to +70°C operating temperature, -30 to +80°C storage temperature, 210.2×164.2×4.9 mm outline, 196.61×147.46 mm active area, 500:1 contrast ratio, 3.3V power supply, 20000-hour LED lifetime and panel model 90-09701-001.

Confirmed Product Specifications

4:3 Control-Panel Fit

The 9.7 inch 1024×768 format is useful when the equipment interface was designed around a 4:3 screen. It can fit access panels, test equipment, industrial controllers, legacy HMIs and service consoles where changing to widescreen would require UI redevelopment. Buyers should confirm whether the existing software expects XGA resolution and whether text size remains readable from the operator position.

LVDS Integration

The confirmed LVDS interface requires host-side review. Engineers should confirm mapping, connector, voltage, cable length, power sequence and backlight control. If the controller board supports HDMI, eDP or TTL only, this panel is not a direct fit without a bridge or controller solution. Provide host-board information during RFQ.

Viewing-Direction Boundary

The detailed table lists 6 o’clock viewing direction. This matters for panel mounting. If the display is installed above eye level, below eye level or in portrait orientation, readability can change. The sample should be tested in the intended enclosure and operator position before approval.

No-Touch Standard Scope

The standard configuration is no touch. If the final control panel needs resistive or capacitive touch, specify touch type, cover lens, bonding, controller interface, ESD and grounding. Touch changes thickness, brightness and mechanical stack, so it should be quoted separately.

Mechanical Review

The 210.2×164.2×4.9 mm outline and 196.61×147.46 mm active area should be checked against the bezel window and mounting frame. Because 4:3 industrial equipment often has tight front panels, verify FPC exit, cable route and gasket pressure before cutting tooling.

Production Control

For repeat orders, lock panel model 90-09701-001, LVDS settings, cable, viewing direction, front stack and inspection criteria. Substitutes should be reviewed for active area, outline, timing and viewing direction before being accepted.

Sample Validation

Sample testing should include LVDS image lock, viewing-direction check, UI readability, brightness uniformity, hot/cold start, cable retention and long-duration operation. If used in access control or service consoles, test the real screens rather than only a color bar pattern.

Why This Page Matters for Legacy 4:3 Equipment

Many industrial systems still use 4:3 screens because the software was designed with fixed control positions, alarm lists and service windows. A move to widescreen can create UI redesign work that the buyer may not want. This 9.7 inch LVDS panel is most useful when the buyer needs a controlled 1024×768 path while keeping the existing HMI layout.

Controller and Cable Evidence

For a reliable quote, provide the current controller board, LVDS cable photo, connector direction and power supply information. If this is a new design, define whether LCDind should provide the cable or only the panel. If it is replacement sourcing, compare the existing screen's viewing direction, active area and outline before assuming compatibility.

Touch Upgrade Decision

Although the base configuration is no touch, 4:3 control panels often use resistive touch or a separate keypad. If the buyer needs touch, confirm touch type, tail position, controller, cover lens and calibration method. A touch upgrade can affect front-window alignment and brightness, so it should be included in the sample acceptance plan.

Acceptance File for Repeat Orders

For production or service inventory, record panel model 90-09701-001, LVDS mapping, cable, sample photos, viewing direction, UI screenshots and inspection limits. This allows future purchasing to compare substitutes against the approved engineering baseline rather than only size and resolution.

Procurement Boundary for This 9.7 Inch Panel

The buyer should decide whether the project needs a bare panel, a cable set, a controller board, touch integration or a complete display module. A bare LVDS panel is appropriate when the host is already fixed and validated. If the customer expects a ready-to-install HMI display, LCDind should quote the panel with cable, controller, front stack and sample-test scope. This avoids comparing a component price with an assembly price.

RFQ Checklist

• Confirm LVDS mapping, connector, voltage, cable length, power sequence and host controller.
• Provide enclosure drawing, visible window, viewing direction, no-touch or touch-stack requirement.
• Define sample quantity, annual forecast, operating temperature and inspection criteria.
• State whether this is replacement sourcing, new OEM design or custom assembly support.

Engineering Review Note

The specifications above are taken from the current public product page and should be treated as selection inputs, not final system approval. Before sample purchase or production order, LCDind should review host interface, drawing, optical stack, touch requirement, controller-board scope, operating environment, supply quantity and inspection criteria. This update keeps the existing product URL unchanged while making the page more useful for B2B engineering and sourcing decisions.

Engineering FAQ

Is touch included?

No. The standard configuration is listed as no touch.

What viewing direction is listed?

6 o’clock in the detailed public table.

Why choose 4:3?

Many industrial interfaces and legacy control panels were designed for 1024×768 geometry.
